Evidence Handling and Preservation

Chain of custody principles

Learning Outcome

4

Maintain evidence authenticity and integrity.

3

Understand ownership and access control.

2

Identify evidence handling procedures.

1

Explain the importance of Chain of Custody in digital forensics.

5

Explain evidence admissibility requirements.

Riya uses her laptop and mobile phone for work. She creates a document, sends an email, browses websites, takes a photo, and sends a WhatsApp message.

These activities create digital footprints such as files, emails, browser history, metadata, and chat records.

Later, an important file is deleted from the computer. An investigation begins to find out what happened.

Investigators look for digital evidence left behind by previous activities.

Investigators examine login records, file details, browser history, and messages to understand who accessed the computer and what actions were performed.

This process is called digital forensic analysis.

The digital records help investigators reconstruct the events and identify important clues.

Digital footprints can become digital evidence during an investigation.

Chain of Custody Principles

Chain of Custody (CoC) is the documented process of collecting, handling, transferring, storing, and presenting evidence while maintaining its integrity until it is presented in court.

Purpose:

Maintains evidence integrity



Prevents tampering or contamination



Records everyone who handled evidence



Supports legal admissibility



Builds trust in investigations

Ownership and Responsibility Tracking

It records who is responsible for evidence during collection, transfer, examination, storage, and court presentation.

     Importance:

Creates accountability

Prevents unauthorized handling

Maintains evidence integrity

Supports legal investigations

Information Recorded:

  • Person's name and designation
  • Organization
  • Date and time

Evidence Transfer Procedures

Evidence Transfer is the controlled movement of evidence between authorized persons or locations while maintaining security and integrity.

     Importance:

Maintains Chain of Custody

Prevents loss or misplacement

Protects against unauthorized access

Allows transfers to be verified

Best Practices:

  • Transfer only when necessary

  • Seal evidence before transport

  • Verify labels and evidence numbers

A complete record of all activities performed on evidence, including collection, transport, examination, storage, and court presentation. It proves that evidence was handled properly and maintains transparency.

Custody Documentation

     Importance:

Provides evidence history.



Supports legal verification.



Shows proper procedures were followed.



Helps review previous activities.



Reduces documentation errors.

Evidence Collection Form:

Records where, when, and how evidence was collected.

01

Chain of Custody Form:

Tracks everyone who handled the evidence.

02

Transfer Records:

Document evidence transfers.

03

Evidence Labeling Standards

Attaching a unique label to each evidence item immediately after collection to identify and track it throughout the investigation.

     Importance:

Provides unique identification.

Prevents confusion or mixing.

Makes evidence easier to track.

Supports accurate documentation.

Improves courtroom credibility.



Label Information

1

Network-Based Evidence

Whenever devices communicate over a network, digital evidence is generated.

Examples

  • Network packets

  • Firewall logs

  • Router logs

  • Switch logs

Network evidence helps investigators trace communication between devices.

2

Cloud-Based Evidence

Cloud services store information on remote servers connected through the internet.

Common Cloud Services

  • Google Drive

  • Microsoft OneDrive

Evidence May Include

  • Documents

  • Photos

Cloud evidence is becoming increasingly important in modern investigations.

Email and Communication Evidence

Electronic communication often contains valuable investigative information.

Emails

SMS messages

WhatsApp chats

Examples:

Investigators examine communication records to determine who communicated, when, and about what.

Web Browser Artifacts

Web browsers automatically store information about user activity.

Browsing history

Cookies

Cached files

Examples:

Browser artifacts help investigators understand internet usage.

Social Media Evidence

Social media platforms contain valuable user-generated information.

Posts

Comments

Messages

Examples:

Social media evidence may help verify user activities and locations.

Log File Analysis

Log files automatically record activities performed by users, applications, and systems.

System logs

Security logs

Application logs

Common Logs:

Log analysis helps investigators reconstruct the sequence of events during an incident.

 Multimedia Evidence (Images, Audio, Video)

Multimedia files are frequently examined during investigations.

Image Evidence

  • Photographs

  • Screenshots

  • Scanned documents

Examples:

Audio Evidence

  • Voice recordings

  • Phone calls

  • Voice notes

Video Evidence

  • CCTV footage

  • Mobile videos

  • Security camera recordings

Portable storage devices are commonly used for transferring digital information.

USB flash drives

External hard drives

Memory cards

Portable SSDs

Examples:

Removable Media Evidence

Documents

Malware

Backup files

Deleted data

Evidence may include:

IoT Device Evidence

Internet of Things (IoT) devices automatically collect and exchange data.

Examples:

Smart watches

Smart TVs

Smart speakers

Smart speakers

Fitness trackers

A Virtual Machine (VM) is a software-based computer running inside another computer.

Virtual machines create their own digital evidence.

Virtual Machine Artifacts

Examples:

Virtual hard disks

VM configuration files

Snapshots

System logs

Metadata Analysis

Metadata means "data about data."

It provides additional information about digital files.

Metadata May Include

Author

Creation date

Last modified date

File size

Camera model

GPS location

Software used

Deleted and Hidden Data Sources

Deleting a file does not always remove it permanently.

Investigators can often recover:

Deleted files

Hidden files

Temporary files

Recycle Bin contents

Unallocated space

These sources may contain valuable evidence.

Encrypted Data Sources

Encryption protects digital information from unauthorized access.

Examples:

Encrypted hard drives

Password-protected files

Encrypted USB drives

Secure messaging applications

Although encryption improves security, it can make forensic investigations more challenging.

Application Artifacts

Applications create records during normal use.

Example

Configuration files

Activity logs

Cache files

Temporary files

Application artifacts help investigators understand how software was used.

Database Evidence

Organizations store important information in databases.

Example

Customer records

Banking transactions

Employee information

Hospital records

Database evidence includes

Digital Evidence Classification Techniques

Based on Storage

  • Volatile Evidence
  • Non-Volatile Evidence

1

Based on Device

  • Computer Evidence
  • Mobile Evidence
  • Network Evidence

2

Based on Data Type

  • Documents
  • Images
  • Audio

3

Based on Accessibility

  • Active Data
  • Deleted Data
  • Hidden Data

4

Summary

5

Cloud, databases, removable devices, and IoT hold evidence.

4

Proper handling maintains evidence integrity and reliability.

3

Deleted or hidden files can be recovered using forensic techniques.

2

Metadata provides details like date, author, and location.

1

Digital activities leave traces that can become valuable evidence.

Quiz

Metadata mainly provides information about:

A. Network speed

B. Computer hardware

C. Details related to a digital file

D. Internet connection

Quiz-Answer

Metadata mainly provides information about:

A. Network speed

B. Computer hardware

C. Details related to a digital file

D. Internet connection
